China Heavy Load Explosion Proof Transfer Cart With Automatic Dumping Device wholesale

Heavy Load Explosion Proof Transfer Cart With Automatic Dumping Device

Name: Heavy Load Explosion Proof Transfer Cart With Automatic Dumping Device
Brand: BEFANBY
Price: 1 USD

Ask Latest Price

Video Channel

Brand Name :BEFANBY

Model Number :KPX

Certification :CE,SGS,ISO9001

Place of Origin :Henan,China

MOQ :1 set/sets

Price :Negotiation

Payment Terms :L/C,T/T,Western Union

Supply Ability :800 set/sets, per year

Delivery Time :40-50 days as usual delivery,30-40days for urgent delivery

Packaging Details :The tranfer cart will be packed by the tarp, the parts will be shipped in the high quality wooden case.

Product name :Heavy Load Explosion Proof Transfer Cart With Automatic Dumping Device

Color :Customized

Application :Industrial field

Running speed :0-20m/min

Running distance :Unlimited

Warranty :24 moniths

Port :Qingdao/Tianjin/Shanghai

Load capacity :1-1000T

Operation type :Hand pendant + remote control

Safe device :E-stop. Sound and light alarm, Dead man stop...

Contact Now

Add to Cart

View Product Description

Heavy Load Explosion Proof Transfer Cart With Automatic Dumping Device

Brief Introduction for Electric Material Transfer Cart

This kind of Heavy Load Explosion Proof Transfer Cart With Automatic Dumping Device is powered by the lead-acid battery which conducts DC current directly into the electrical control system of the railway platform to let it start, stop, go forward and backward, speed up and slow down and so on.This electric railway platform can be used both on the "s"and arc-shaped railways and suitable for long distance tracelling.Roll plant electrical control system handle box sand blasting room transfer materials

Structure

This kind of series Anti High Temperature Material Moving Carts , High Speed Material Transfer Carts metal ladle for foundry is composed by electric railway frame, the electric motor, gear reducer, wheel, electrical appliance box, lead-acid battery, shaft and connecting shaft, handle box, alarm light, buffer device, pendant control or wireless remote control and some other accessories and so on. roll plant electrical control system handle box sand blasting room transfer materials

Application

The Anti High Temperature Material Moving Carts , High Speed Material Transfer Carts metal ladle for foundry is suitable for various industries;

Steel mill: transfer steel products such as steel structure, steel pipe, steel billets, steel ladle and coil, etc

Paper roll plant: transfer paper coil Painting shops: transfer workpiece into the painting room Sand blasting room Other industries: shipbuilding, quarries, warehouses and multi-bay workshops, etc

Chemical plant: Transfer materials and large machine parts;

Building Sites: Load cement concrete and building machinery;

Port: used for the container and cargoes shuttle;

roll plant electrical control system handle box sand blasting room transfer materials

Technique Parameter

Model		KPX-2t	KPX-5t	KPX-10t	KPX-16t	KPX-20t	KPX-25t	KPX-30t	KPX-40t	KPX-50t	KPX-63t	KPX-80t	KPX-100t	KPX-150t
Rated Load		2	5	10	16	20	25	30	40	50	63	80	100	150
Table size	Length(L)	2000	3500	3600	4000	4000	4500	4500	5000	5500	5600	6000	6500	10000
	Width(W)	1500	2000	2000	2000	2200	2200	2200	2500	2500	2500	2600	2800	3000
	Height(H)	450	500	500	550	550	600	600	650	650	700	800	900	1200
Wheel Base		1200	2500	2600	2800	2800	3200	3200	3800	4200	4300	4700	4900	7000
Rail Inner Gauage		1200	1435	1435	1435	1435	1435	1435	1435	1435	1435	1800	2000	2000
Wheel Diameter		270	300	300	350	350	400	400	500	500	600	600	600	600
Wheel Quantity		4	4	4	4	4	4	4	4	4	4	4	4	8
Ground Clearance		50	50	50	50	50	50	50	50	50	75	75	75	75
Running Speed		25	25	25	20	20	20	20	20	20	20	20	20	18
Motor Power		1	1.2	2	2.2	3	3.5	4	5	6.3	8	10	15	15
Battery Capacity		180	180	160	180	180	250	250	300	330	400	400	440	600
Battery Voltage		24	36	48	48	48	48	48	48	48	48	72	72	72
Running Time When Full Load		4.32	5.4	4.8	4.3	4	4	3.5	3.6	3.3	3	3.6	3.2	2.9
Max Wheel Load		14.4	25.8	42.6	64.5	77.7	94.5	110.4	142.8	174	221.4	278.4	343.8	265.2
Reference Weight		2.8	3.6	4.2	5.5	5.9	6.5	6.8	7.6	8	10.8	12.8	14.6	26.8
Recommended Rail Model		P15	P18	P18	P24	P24	P38	P38	P43	P43	P50	P50	QU100	QU100

Our Company

Xinxiang Hundred Percent Electrical and Mechanical Co., Ltd is a collection of research, design, manufacture, installation and after-sales service of electric handling bogie ,transfer carts as one of the professional manufacturing company, which has a modernized management team and excellent staff.And our prodcuts gets CE, SASO,SGS,ISO certificate and other 8 national patent, our products have been exported to more than 40 countries and regions,such as Germany, Mexico, USA, Turkey, South Africa, Singapore etc. roll plant electrical control system handle box sand blasting

Our Advantage

Our Customer

Production Supply Scope

Product Name	Model No.	Power Supply Mode	Load Capacity	Usage
Rail Transfer Cart	KPD	Conductor Rail	Load range 1-500ton, can be customized per client demand	Ordinary goods,such as steel plate, workpiece,equipment etc special goods,such as coil. column,ladle etc
Battery Powered Transfer Car	KPX	Battery
Motorized Transfer Trolley	KPJ	Cable Drum
Busbar Powered Handling Cart	KPC	Busbar
Towed Rail Trailer	KP	Tractor	1-500t
Steerable Towed Car	BWT	Tractor	Load range 1-500t, less than 20t, cement floor is ok. More than 20t,steel floor is demanded.
Trackless Handling Machine	BWP	Battery

These points we need to learn:

1.The load capacity of the transfer cart is ( ) ton.

2.The table size is ( ) mm (L) *( ) mm (W)*( ) mm (H).

3.The voltage is ( ) V,( ) HZ, 3 phase.

4.The running time is ( ) hours per day.

5.The running distance is ( ) m per time.

6.The transfer cart runs on the rails or common floor?

7.Whether exist turning?

8.Whether has other special requirement?
